| Technical Specification | ||
|---|---|---|
| Storage Capacity | Fingerprint Capacity | 2000 |
| CPU | 264MHz | |
| Flash Memory | 8MB | |
| Communication Interface | 232-TTL/USB | |
| Sensor | 500 DPI Optical Sensor | |
| Template Size | <2048 Bytes | |
| Image Capture Area | 15.24x20.32mm (FAP20) | |
| Image Size(px) | 300x400 | |
| Finger Rotation | 360o | |
| Supply Voltage | 5V-250mA scanning | |
| 5V-25mA idle (Waiting for Fingerprint) | ||
| Dimensions | 36.2x44.2x15.85mm (LxWxH) | |
| Optional Feature | Anti fake within limit | |
| Features | ||
| Easy Integration by smallest size without any extra accessories | ||
| Durable glass touch surface | ||
| Stable operation under strong light source | ||
| Quick recognition of dry, wet and rough fingers | ||
